7X19 STEEL WIRE ROPE

Nominal Diameter

Approx.Weight

1470

1570

1670

1770

1870

Minimum Breaking Load of Rope

d

Allowed
Tolerance

NF

SF

IWR/IWS

FC

IWR/IWS

FC

IWR/IWS

FC

IWR/IWS

FC

IWR/IWS

FC

IWR/IWS

mm

%

kg/100m

KN

3

+8

3.11

3.03

3.43

4.06

4.39

4.34

4.69

4.61

4.99

4.89

5.29

5.17

5.59

4
5

+7
0

5.54
8.65

5.39
8.43

6.10
9.53

7.22
11.30

7.81
12.20

7.71
12.00

8.34
13.00

8.20
12.80

8.87
13.90

8.69
13.60

9.40
14.70

9.19
14.40

9.93
15.50

6
7
8
9
10
11
12
13
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50

+6
0

12.50
17.00
22.10
28.00
34.60
41.90
49.80
58.50
67.80
88.60
112.00
138.00
167.00
199.00
234.00
271.00
311.00
354.00
400.00
448.00
500.00
554.00
610.00
670.00
732.00
797.00
865.00

12.10
16.50
21.60
27.30
33.70
40.80
48.50
57.00
66.10
86.30
109.00
135.00
163.00
194.00
228.00
264.00
303.00
345.00
390.00
437.00
487.00
539.00
594.00
652.00
713.00
776.00
843.00

13.70
18.70
24.40
30.90
38.10
46.10
54.90
64.40
74.70
97.50
123.00
152.00
184.00
279.00
258.00
299.00
343.00
390.00
440.00
494.00
550.00
610.00
672.00
738.00
806.00
878.00
953.00

16.20
22.10
28.90
36.60
45.10
54.60
65.00
76.30
88.50
116.00
146.00
181.00
218.00
260.00
305.00
354.00
406.00
462.00
522.00
585.00
652.00
722.00
796.00
874.00
955.00
1040.00
1130.00

17.60
23.90
31.20
39.50
48.80
59.10
70.30
82.50
95.70
125.00
158.00
195.00
236.00
287.00
330.00
383.00
439.00
500.00
564.00
632.00
705.00
781.00
861.00
945.00
1030.00
1720.00
1220.00

17.40
23.60
30.80
39.00
48.20
58.30
69.40
81.50
94.50
123.00
156.00
193.00
233.00
278.00
326.00
378.00
434.00
494.00
557.00
625.00
696.00
771.00
850.00
933.00
1020.00
1110.00
1200.00

18.80
25.50
33.40
42.20
52.10
63.10
75.10
88.10
102.00
133.00
169.00
208.00
252.00
300.00
352.00
409.00
469.00
534.00
603.00
676.00
753.00
834.00
919.00
1010.00
1100.00
1200.00
1300.00

18.50
25.10
32.80
41.50
51.30
62.00
73.80
86.60
100.00
131.00
166.00
205.00
248.00
295.00
347.00
402.00
461.00
525.00
593.00
664.00
740.00
820.00
904.00
993.00
1080.00
1180.00
1280.00

20.00
27.20
35.50
44.90
55.40
67.10
79.80
93.70
109.00
142.00
180.00
222.00
268.00
319.00
375.00
435.00
499.00
568.00
641.00
719.00
801.00
887.00
978.00
1070.00
1170.00
1280.00
1390.00

19.60
26.60
34.80
44.00
54.30
65.80
78.20
91.80
107.00
139.00
176.00
217.00
263.00
313.00
367.00
426.00
489.00
556.00
628.00
704.00
785.00
869.00
959.00
1050.00
1150.00
1250.00
1360.00

21.20
28.80
37.60
47.60
58.80
71.10
84.60
99.30
115.00
150.00
190.00
235.00
284.00
338.00
397.00
461.00
529.00
602.00
679.00
762.00
849.00
940.00
1040.00
1140.00
1240.00
1350.00
1470.00

20.70
28.10
36.70
46.50
57.40
69.50
82.70
97.00
113.00
147.00
186.00
230.00
278.00
331.00
388.00
450.00
517.00
588.00
664.00
744.00
829.00
919.00
1010.00
1110.00
1210.00
1320.00
1440.00

22.40
30.40
39.70
50.30
62.10
75.10
89.40
105.00
122.00
159.00
201.00
248.00
300.00
358.00
420.00
487.00
559.00
636.00
718.00
805.00
896.00
993.00
1100.00
1200.00
1310.00
1430.00
1550.00
